4 powerful LEDs 2 W SMD 8072 2in1 BCL CW/UV (homogenous color mix) LEDs controlled separately
1 x device, 1 x power cord, 1 x user manual, 1 x declaration of conformity, 1 x remote control, 1 x foot control, 2 x knurled screw, 2 x washer, 2 x mounting bracket, 2 x battery, 1 x bag
Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
150 W
IP classification:
IP20
Protection class:
Protection class I
Power connection:
Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Power output:
1 x IEC connector (F) mounting version
Fuse:
5 x 20 mm, T 3.15 A
Lamp type:
LED lamp
DMX channels:
3; 5; 10; 28
DMX input:
1 x 3-pin XLR (M) mounting version
DMX output:
1 x 3-pin XLR (F) mounting version
Cooling:
Cooling fan
Control:
Stand-alone; DMX; IR remote control; sound to light via microphone; wireless footswitch; master/slave function
Preprogrammed in:
EASY SHOW 1; Light´J; LED PC-Control 512; Light Captain; EASY SHOW 2; EASY SHOW 3; Colorchief
Housing color:
Black
Attachment system:
2x mounting bracket
Dimensions:
Width: 1.030 cm Depth: 6.1 cm Height: 38.7 cm
Weight:
10.00 kg
Noise classification:
Class 2 (slight noise)
Power cord
Cable length:
3 m
Remote control
Battery:
1 x button cell 3.0 V CR2025 lithium manganese built-in
Foot control
Battery:
1 x 9.0 V E block 6F22 zinc carbon included
Laser
Laser class:
2M
Laser color:
R/G
Laser module:
Red (R) 100 mW 650nm Green (G) 30 mW 532nm
Light effect
LED type:
6 x 2 W SMD 8072 R/G/B
Flash rate:
0 - 30 Hz
Spotlight
LED type:
6 x 6 W SMD 8072 3in1 TCL RGB (homogenous color mix)
Beam angle:
13°
Beam angle (1/2 peak):
13°
Beam angle (1/10 peak):
20°
Bar
LED type:
4 x 2 W SMD 8072 2in1 BCL CW/UV (homogenous color mix)
