Each microphone input with optional 12 V phantom power
FX send/return with FX level control
Stereo master out (6.3 mm jack) with 2-band equalizer (highs and lows) and level control
Stereo record output (RCA)
(19) 48.3 cm rack installation 1 U
For application areas such as: Installation; restaurants, bars and hotels; clubs/dancing school
1 x device, 1 x power cord, 1 x user manual
Power supply:
115/230 V AC, 50/60 Hz
Power consumption:
5 W
Protection class:
Protection class I
Power connection:
Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Frequency range:
20 - 20000 Hz
Phantom power:
12 V DC
Housing color:
Silver
Control elements:
Phantom power switch, power switch, FX send/returne control
Status LED:
Power, clip
Connections:
Input: mic/line via 3 x 3-pin XLR Input: line via 3 x stereo RCA Input: FX via 2 x 6.3 mm jack socket (mono) mounting version Output: rec. via 1 x stereo RCA Output: master via 2 x 6.3 mm jack socket (mono) mounting version Output: FX via 1 x 6.3 mm jack socket (stereo) mounting version
Channels:
Input channel: 3 x stereo via RCA, channel control via rotary dial, 2-band tone control EQ 100Hz/10kHz Microphone channel: 3 x mono with mic-line switch via XLR, channel control via rotary dial, 1 Send/AUX, FX routing switch Master output: 1 x stereo via jack, channel control via rotary dial
