Comfortable control of PA speakers via 6-zone technology
6 PA zone outputs, independently switchable on the front panel
Output for low-impedance speakers (4-16 ohms)
2 rear microphone inputs (6.3 mm jack, unbal.)
1 front microphone input (combination XLR/6.3 mm jack, unbal.) with adjustable priority circuit
All microphone inputs with separate level controls
3 line inputs (stereo RCA) with separate level controls
1 line output (stereo RCA)
Chime, switchable
Treble and bass control for the output signal
7-digit LED level meter
Master control for the output signal
(19) 48.3 cm rack installation 2 U
The device is cooled by cooling fan
For application areas such as: Installation; restaurants, bars and hotels; sports centres/gyms
1 x amplifier, 1 x user manual
Power supply:
230 V AC, 50 Hz
Power consumption:
700.00 W
Protection class:
Protection class I
Output power:
350 W RMS
Power connection:
Fixed power supply cord with safety plug
Device fuse:
5 x 20 mm, T 5 A fuse replaceable
Frequency range:
80 - 16000 Hz
S/N ratio:
>75 dB microphone >85 dB line
THD:
<0.5 % at 1 kHz
Cooling:
Cooling fan
Impedance:
Public address systems 100V; 4-16 ohms; Public address systems 70V
Housing color:
Black
Zone output:
6 switchable zones
Circuitry:
Class AB
Control elements:
Power switch, Master control, level control per channel, tone control, regular talkover
Controls:
Power on/off transient; Overvoltage; short-circuit
Status LED:
Power, fault, level meter, zone output
Connections:
Input: microphone via 2 x 6.3 mm plug (unbal.) Input: microphone via 1 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version) Input: line via 3 x stereo RCA 0.3 V Output: speaker via screw terminal Output: rec. via 1 x stereo RCA
